1. The box is a design integrating air curtain with the static electricity eliminator using high frequency AC method. Efficiently eliminate static electricity and dust, as well as collect dust.
2. The air pressure can be adjusted. The photoelectric switch controls the gas switch. This machine can be used on both table work and assembly line.
3. This machine has a small size, a light weight and full functions. The elimination is faster and more thorough.
4. External material: Stainless steel, Plexiglass, transparent windows for easy observation.
Parameter of static dust-proof box
|
Technical parameters
|
|
Product model
|
SD1 |
SD2 |
SD3
|
|
Input power supply voltage
|
AC220V/50HZ
|
|
Output voltage
|
DC 24V
|
|
Install the anti-static appliances
|
NOZZLE*1
|
|
Current consumption
|
1100mA~1500mA
|
1100mA~1500mA
|
2200mA
|
|
Loaded destaticizing
|
NOZZLE (1set)
|
NOZZLE (1set)
|
NOZZLE (2sets)
|
|
Ion balance
|
Automatic ion balance system 0±15V
|
|
Applied airflow
|
Air (clean air containing no water or oil)
|
|
Electric actions time
|
0~30s free setting
|
|
Operating pressure
|
0.05-0.7Mpa free setting
|
|
Anti-static property
|
(within ± 1000 - ±100/ls/200mm/0.4Mpa) ±15V
|
|
Applied environment temperature
|
0 ~40℃ (no condensation)
|
|
Applied environment humidity
|
30-70% RH (no water drop condensation)
|
|
Piping connecting
|
Φ10 quick coupling
|
Φ8 quick coupling
|
Φ10 quick coupling
|
|
Openings size(mm)
|
195 X 130
|
155X123
|
450X258.5
|
|
Overall size(mm)
|
336X 343X201
|
280X245X164
|
456X407.5X375
|
|
Work action area(mm)
|
195X186X130
|
158X140X120
|
450X258.5X175
|
|
Weight (kg)
|
7.8
|
4.6
|
23.5
|
|
Anti-static test
|
| Operating voltage: DC24V Test voltage: ±1000V-±100V Ambient temperature: 23℃±2℃ |
|
Distance
|
200mm
|
300mm
|
|
Destaticizing time
|
Positive
|
0.7s
|
1.1s
|
|
Negative
|
0.9s
|
1.3s
|
|
Residual voltage
|
Positive
|
<0±15V
|
|
Negative
|
